OPTOTRONIC FIT D CS L
EAN: OPTOTRONIC FIT D CS L
Sales unit
View downloads
- 1 pcs
- Supply voltage: 220…240 V
- Line frequency: 50 Hz | 60 Hz
- Line voltage: 198…264 V
- Safety and performance according to IEC 61347-1, IEC 61347-2-13, IEC 62384
- RI suppression according to CISPR 15
- Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
- Immunity according to IEC 61547
- Non-isolated drivers
- Versatile scope of application due to output power range of up to 65 W
- Safety requirement due to overload, overtemperature, short-circuit protection
- User flexibility with four different output currents from one driver
- Linear and area lighting
- Office, industrial and shop lighting
- Suitable for luminaires of protection class I
Products
| Product | Nominal output voltage | Nominal output current | Data sheet |
OT FIT 65/220-240/350 D CS L
|
70…220 / 70…190 V | 200 / 250 / 300 / 350 mA | |
OT FIT 75/220-240/350 D CS L
|
70…220 V | 200 / 250 / 300 / 350 mA | |
OT FIT 35/220...240/350 D CS L
|
40…160 / 40…115 V | 200 / 250 / 300 / 350 mA |
