ELEMENT EM FIT NON SELV
EAN: ELEMENT EM FIT NON SELV
Sales unit
View downloads
- 1 pcs
- Line frequency: 50 Hz | 60 Hz
- Supply voltage: 220…240 V
- Lifetime: up to 50,000 h (temperature at Tc max. = -10 °C, max 10% failure rate)
- Wide output voltage range
- Fixed output (no dimming)
- Small housing design
- Flexible current setting (DIPswitch – 4 currents)
- High efficiency and reliability
- Enhanced safety due to overload, overtemperature, short-circuit protection
- High light quality due to low ripple current
- Long lasting and high reliability
- Linear and area lighting
- Shop lighting
- Offices, Public buildings, Supermarkets
- Industry lighting
- Suitable for luminaires of protection class I and II
- Suitable for luminaires of protection class I
Products
| Product | Nominal output voltage | Nominal output current | Data sheet |
EM FIT 40/220-240/350 D CS L
|
40…120 V | 200 / 250 / 300 / 350 mA | |
EM FIT 60/220-240/350 D CS L
|
90…175 V | 200 / 250 / 300 / 350 mA | |
EM FIT 75/220-240/550 D CS L
|
90…216 V | 350 / 400 / 500 / 550 mA | |
EM FIT 18/220-240/350 D CS L
|
27…54 V | 200 / 250 / 300 / 350 mA |
